27 - 19
27.16.6 The QoS Tab
27.16.7 The ADT Tab
The ADT (admit-discharge-transfer) gateway is normally deployed in the eGateway. You can obtain patient
information from the hospital ADT server through the ADT gateway.
27.16.8 The HL7 Configuration Tab
You can send the realtime data, waveforms, and alarms from the monitor to the hospital servers via HL7
protocol. This page also display the server connection status.
Menu Item Default Setting Description
QoS Level For Realtime Monitoring 0 Selects the service quality of network connection
for realtime monitoring, for example parameter
measurements and waveforms, alarms, and so on
QoS Level For Others 0 Selects the service quality of network connection
for non-realtime monitoring, for example history
data, printing, and as on.
Menu Item Default Setting Description
Server Address 192.168.0.100 Input the host name or IP address of the ADT
gateway.
IP Address 192.168.0.100
Port 3502 Input the port of the ADT gateway.
ADT Query Off Selects whether patient information can be
loaded to the monitor from the ADT server.
Network Test / Tests whether the ADT server is properly
connected.
Section Menu Item Default Setting Description
Data + Waveforms Server Address 0.0.0.0 Inputs the name or IP address for the server
receiving the realtime data and waveform.
Destination IP 0.0.0.0
Port 0 /
Send Data Off
Data Interval 30 sec
Send Waveforms Off
Alarms Server Address 0.0.0.0 Inputs the name or IP address for the server
receiving the alarm data.
Destination IP 0.0.0.0
Port 0 /
Send Alarm Off
