2 - 3
2.3.1.2 Left View
â—† On: when the power is connected.
â—† Off: when the power is not connected.
(8) Battery indicator
â—† Yellow: the battery is being charged.
â—† Green: the battery is fully charged.
â—† Flashing green: the monitor operates on battery power.
â—† Off: no battery is installed, or the battery is malfunctioning, or the monitor is powered off and
no power is connected.
(9) Power switch
â—† Pressing this switch turns on the monitor.
â—† When the monitor is on, pressing and holding this switch turns off the monitor.
(1) Temperature probe connector (2) SpO
2
probe connector
(3)IBP cable connector (4) ECG cable connector
(5) CO
2
watertrap seat (6) NIBP cuff connector
(7) Gas outlet (8) C.O. cable connector
(2) (3) (4)
(1)
(8) (7) (6)
(5)
