4.7.7.3.2 Search for connected load cells
In this menu item (under Calib), a search is performed for connected load cells of the
digital weighbridge load cell Pendeo
®
Truck.
Accessible via MENU – [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Search for connected load cells].
WP-D Max 192t d= 0.02t
0.000 t
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
WP-D Max 192t d= 0.02t
0.000 t
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
?
Search for connected load cells.
The current settings are reset
to default values.
Cancel Continue
Press the [Cancel] soft key to return to the Pendeo setup menu.
1. Select and conrm [Search for connected load cells].
A prompt window opens.
2. Press the [Continue] soft key to start the search.
Max -------?? d= -------??
scale not ready
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
searching for load cells...
4 Load cells found
The search is started.
