NOTICE
Potential network problems
A unique device name must be assigned for the hardware conguration and
assignment/download.
4.7 Weighing points
In this menu item (under System setup), the corresponding weighing electronics are
assigned to a logical weighing point and congured.
- [Internal weighing point], see Chapter 4.7.1.
- [Liquid counter], see Chapter 4.7.2.
- [User scale], see Chapter 4.7.3.
- [xBPI scale], see Chapter 4.7.5.
- [SBI scale], see Chapter 4.7.6.
- [Pendeo Truck], see Chapter 4.7.7.
- [Pendeo Process], see Chapter 4.7.8.
- [PR-Net weighing point], see Chapter 4.7.9.
- [Mettler-Scale], see Chapter 4.7.10.
- [SMA scale], see Chapter 4.7.11.
The device can manage up to four weighing points (scales). The number of scales to be
used is determined by the application package. There are physical weighing electronics/
scales (e.g. [internal], [xBPI scale]) and logical weighing points (WP A, WP B, WP C, and
WP D).
A totalization of two scales can only take place on C = A+B.
Restrictions when selecting scale protocols:
- A maximum of three digital scale protocols (excluding SBI) are possible at the same
time:
- xBPI
- Pendeo
- A maximum of two digital scale protocols are possible if [Operating] - [System setup]
- [Connected devices] - [ModBus-RTU master] has been selected in the menu.
The physical weighing point can be assigned to a logical weighing point in the menu
[Operating] - [System setup] - [Weighing points] in accordance with the following table:
Weighing electronics Logical weighing point
WP‑‑A WP‑‑B WP‑‑C WP‑‑D
[not assigned] W W W W
[Internal weighing point] W W - -
[A+B] - - W -
[Liquid counter] W W W W
