2.9 Operating via a notebook/PC
The following options are possible:
- Via VNC Viewer (on the enclosed CD-ROM), see Chapter 2.9.5.
- Via the internet browser, see Chapter 2.9.6.
Requirement:
The Java application must be supported by the web browser.
2.9.1 Finding and connecting the device automatically in the network
If the DHCP server is active in the network, the connected device (if activated in the menu
[Operating] - [Default conguration] - [Network parameters] - [use DHCP]) is
automatically assigned an IP address.
On the notebook/PC, the host names of the connected devices in the network are listed
under [Network].
Double-click the host name to open the device page in the web browser. The IP address is
displayed on the bottom right.
Note:
If the web browser supports the Java application, the device can be operated via[remote
conguration (VNC).]
If the web browser does not support the Java application, the menu items will be
inaccessible (grayed out).
2.9.2 Finding and connecting a device with a notebook/PC
If the device is connected to a notebook/PC via a point-to-point connection, an IP
address is negotiated via function "AutoIP". This can take up to 2 minutes!
NOTICE
When the IT/DHCP network cable is temporarily connected between the notebook/
PC and a device, the DHCP server is lost and the notebook/PC returns to the auto-IP
address within approx. two minutes!
Reason: The DHCP server/client relationship is checked cyclically at 23-minute
intervals.
15. Re-enter the network settings (as noted previously) on the notebook/PC.
Note:
Resetting the network settings (see also Chapter 2.8.2) by:
- Holding down the reset button for > 5 s, see Chapter 2.9.4.
- Selecting and conrming the menu [Operating]- [System setup]- [Network
parameters]- [Default] .
The blackbox device will now be available on the network under the new address
and ready for operation.
Process Controller Maxxis 5 PR 5900 2 Commissioning
Minebea Intec EN-26
