[/ Scale counts]
WP-D Max 1000kg d= 1kg
0
kg
Weighing points @admin
1
2
3
Weighing point D
/ Scale Counts
Overload
Minimum weight
Update time
Liquid counter
1 cnt
9 d
0 d
0.3 s
Default Save
Number of scale counts for the weight increase entered under [Scale Weight /].
Setting range: 1…65000.
[Overload]
Weighing range above the maximum capacity (Max) without error message.
Setting range: 0…9999999 d.
[Min. weight]
Minimum weight at which a print command can be triggered.
Setting range: 0…9999999 d.
[Update time]
Timeframe in which a new weight value is displayed.
Setting range: 0.1…2.0 s.
[Default] soft key
Settings are reset to factory settings.
4.7.3 User scale
In this menu item (under Weighing points), the user scale weighing electronics are
assigned to a logical weighing point and congured.
- Parameters (weighing electronics), see Chapter 4.7.3.1.
The user-dened weighing point receives data via SPM‑Variable. The value contained in
this variable is scaled and displayed as the weight value.
This function is used e.g. for
- Describing the SPM‑Variable of the OPC server
- Projects
Accessible via MENU - [Operating]- [System setup]- [Weighing points]- [Weighing
point x]- [Weighing point]- [User scale] .
3. Press the [Save] soft key to save the settings.
In the [Weighing points] menu, the weight can be displayed with an increased
resolution (10-fold); see Chapter 3.8.
Process Controller Maxxis 5 PR 5900 4 System setup
