Byte Field Description
4 Read_Value_Select Selects the function for reading
data.
5 Write_Value_Select Selects the function for writing
data.
6 free free free free free free free free
7 free free Res
Power
Res
Test
Set
Test
Res
Tare
Set Ta-
re
Set
Zero
In direct access, control bits are
independent of the write or read
request. "Free" bits are applica-
tion specic.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Field Size Function
Write data 4 bytes Data to be written as a binary 32-bit value with plus or
minus sign.
Data type: DINT
Read_Value_Select 1 byte Function for selecting the read request
Write_Value_Select 1 byte Function for selecting the write request
ResPower 1 bit PowerFail is reset.
ResTest 1 bit The test operating mode is nished.
SetTest 1 bit The test operating mode is started.
Now the test value can be read out by reading the
gross weight.
ResTare 1 bit Tare is reset.
SetTare 1 bit The weighing point is tared.
SetZero 1 bit The weighing point is set to zero.
8 Fieldbus interface Process Controller Maxxis 5 PR 5900
EN-347 Minebea Intec
