Function number 10 Current tare value, if tared; otherwise 0
Function number 11 Only if supported by the application: current gross/net
weight selected.
Otherwise: Reserved for internal use.
Function number 12 Current gross value in internal resolution (1/100d)
Function number 13 Current tare value in internal resolution (1/100d)
Function number 14 Max (FSD)
Function number 15 Min
8.2.5.9 Function number 80 to 89: state-controlled action bits (write)
Note:
For setting bits, see Chapter 8.2.2.3.
Only setting and resetting of single bits is possible.
When changing a bit from 0 to 1, the corresponding action starts. After handling the
command, the bit must be reset. Application: The master writes cyclically.
The bit is set as Write_Value_Select with the specied number (see Chapter 8.2.2.3).
The bit is reset at the specied number +128.
Function number 80 SetZero Set the gross weight to zero.
Function number 81 SetTare The weighing point is tared.
Function number 82 ResetTare Reset tare.
Function number 83 SetTest Start the ADC test.
Function number 84 ResetTest Finish the ADC test.
Function number 85 ResetPwf Reset the PowerFail bit (function num-
ber 1; the bit was set after "power on").
Function number 86 SetFixTare Taring with weight in numerical address
e.g. D31 (weighing point A) "Fixtare".
Function number 87 GetFixTare The current gross weight is copied to
the numerical address e.g. D31
(weighing point A).
Function number 89 ResetError The CmdError error bit is reset.
8.2.5.10 Function number 112 to 119, 121: transition-controlled action bits (write)
For setting bits, see Chapter 8.2.2.3.
As soon as the bit is set, it is reset internally and the operation is processed in a transition-
controlled manner (for a single write).
The bit is set as Write_Value_Select with the specied number (see Chapter 8.2.2.3).
Function number 112 SetZero
8 Fieldbus interface Process Controller Maxxis 5 PR 5900
EN-355 Minebea Intec
