Mitsubishi MELSEC iQ-F FX5 series User Manual

2 CPU MODULE INSTRUCTION
2.2 Basic instruction
49
2
■Adding/subtracting 32-bit binary data
■Multiplying/dividing 16-bit binary data
Instruction symbol Description Reference
D+ [(d)+1, (d)] + [(s)+1, (s)]  [(d)+1, (d)] Page 169
D+P
D+_U
D+P_U
D+ [(s1)+1, (s1)] + [(s2)+1, (s2)]  [(d)+1, (d)] Page 170
D+P
D+_U
D+P_U
DADD [(s1)+1, (s1)] + [(s2)+1, (s2)]  [(d)+1, (d)] Page 171
DADDP
DADD_U
DADDP_U
D- [(d)+1, (d)] - [(s)+1, (s)]  [(d)+1, (d)] Page 173
D-P
D-_U
D-P_U
D- [(s1)+1, (s1)] - [(s2)+1, (s2)]  [(d)+1, (d)] Page 174
D-P
D-_U
D-P_U
DSUB [(s1)+1, (s1)] - [(s2)+1, (s2)]  [(d)+1, (d)] Page 175
DSUBP
DSUB_U
DSUBP_U
Instruction symbol Description Reference
*(s1)  (s2)  [(d)+1, (d)] Page 177
*P
*_U
*P_U
MUL (s1)  (s2)  [(d)+1, (d)] Page 178
MULP
MUL_U
MULP_U
/(s1)  (s2)  quotient (d), remainder (d)+1 Page 180
/P
/_U
/P_U
DIV (s1)  (s2)  quotient (d), remainder (d)+1 Page 181
DIVP
DIV_U
DIVP_U
