Dust Control/DustGuard

™

Systems 100Service Manual – CS7000

Specications

Component Specications

DustGuard Pump

Type - Diaphragm w/bypass

Nominal Voltage - 36 VDC

Flow Rate - 1.1 GPM

Current - 1.0 Amp max.

Pressure - 30 psi max.

DustGuard Solenoid Valve

Nominal Voltage - 36 VDC, 11 Watts

Coil Resistance - 125 Ohms ± 10%

Dust Control Filter

Media Type - synthetic with UltraWeb (cellulose optional)

Media Quantity - 120 ft

(approximate)

Media Conguration - PowerCore

Dust Control Vacuum Motor Current - 7 Amps average, 8 Amps max.

Dust Control Motor Contactor

(K6)

118 Ohms ± 10%

Dust Control Filter Switch

Actuation setting ± 20%: factory set at 2” H

O/0.147”

Hg/0.072 psi

Filter Shaker Motor

Voltage - 36 VDC

Current - 0.8 Amps average

Power - 90 Watts

Ingress Protection - IP44

Insulation Class - B

Duty - intermittent (S2 10 min.)
