General Information 19Service Manual – CS7000
Jacking the Machine
Warning! Never work under a machine without safety stands or blocks to support the machine.
When jacking the machine, do so at the designated Tie Down/Jacking Locations.
Transporting the Machine
Caution! Before transporting the machine on an open truck or trailer, make sure the machine
is tied down securely and all access doors and covers are secured (tape and strap as
needed).
The jacking and tie-down locations are identied with a graphic molded
into the exterior body panels.
The jacking and tie-down locations are in front of the front wheels, and at the rear of the machine below the
solution tank.
Rear Jacking/Tie-down LocationFront Jacking/Tie-down Location
Jacking/
Tie-down
Location
