Recovery System 300Service Manual – CS7000

Specications

Component Specications

Vacuum Motor

Voltage - 42 VDC

Insulation Class - A

Current Draw

Average - 15 Amps

Maximum - 17 Amps

Vacuum System Vacuum

Sealed – 48” H

2

O

With 1” dia. Orice – 25” to 30” H

2

O

Special Tools

Vacuum water lift gauge, Nilsk-Advance part number 56205281
