278Service Manual – CS7000 278

Options and Accessories

Description Illustration

Seat Belt Kit

Recovery Tank Clean Out Kit

The Recovery Tank Clean Out Kit

includes a removable Recovery

Tank Clean Out Door

to allow

easier cleaning and ushing of the

Recovery Tank.

Back-Up Alarm Kit

The Back-Up Alarm Kit includes the

Back-Up Alarm, electrical connector

and mounting hardware. The Back-

Up Alarm connects to the existing

machine wiring to sound a warning

when the machine is moving in

reverse.

Recovery Tank

Clean Out Door

Recovery

Tank
