Sweep System, Main 384Service Manual – CS7000

Inspecting/Replacing Main Broom Motor Carbon Brushes

1. Remove the main broom motor and gearbox assembly. See the Removal and Installation section.

2. Create witness marks on the gearbox, motor end bells (covers) and the motor casing for reassembly.

3. Remove the gearbox from the motor.

Note: Weep Hole

faces oor when

installed
