Nilfisk-Advance CS7000 Service Manual

Electrical System 112Service Manual – CS7000
Connector Pin-Outs
The following pages contain details about every electrical connector that contains more than one “cavity”.
The connector pin-out information is organized with a table on the left which identies the location of wires
in the connector and images on the right which show what the connector looks like. The table on the left has
a header that describes the connector ID, the name of the component that it plugs into and the component’s
ID number. (There are a few connectors that do not plug into a component but plug into another harness
or are empty. These have the connector ID and the “name” of the connector only.) The images to the right
of each table have a “3 dimensional” view of the connector to help you recognize it on the machine and a “2
dimensional” view of the “back side” or “wire side” of the connector. This is to help you match up the wires
and pin numbers of the connector.
The connector pin-out information is organized by the connector ID in alphabetical order. If you are viewing
this document on a computer, you can search for the component ID or component name to nd the pin out
chart. However, if you are viewing a paper copy, it will be easier for you to nd the correct pin-out table if
you know the connector ID. To learn the connector ID, nd the component ID from the wiring diagram. Then
use the “Component ID to Connector ID Look Up Table” below to nd the connector ID.
Component ID to Connector ID Look Up Table
Component ID Component Name Connector ID
A1 Main Machine Controller J2
A1 Main Machine Controller J3
A1 Main Machine Controller J7
A2 Drive controller J4
A3 Control panel J1
A5 Steering controller J5
B1 Brush Motor Current Sensor X183
B2 Broom Motor Current Sensor X181
B3 Vacuum Motor Current Sensor X182
E4 Steering wheel sensor X98
H1 Back up alarm (Optional) X178
J8 Can bus programmer connector J8
J10 Drive Controller Programmer J10
L1 Solution Solenoid Valve X190
L2 Dust guard valve X140
LT1 Trouble light X258
LT2 Right headlight X162
LT3 Left headlight X161
LT5 Taillight, right X154
LT6 Taillight, left X153
LT8 Curb light (optional) X165
LT9 Stop turn light, left X180
LT10 Beacon (optional) X257
LT11 Stop turn light, right X184
M1 Main Broom motor X25
M2 Motor, left brush X19
M3 Motor, center brush X18
M4 Motor, right brush X17
M5 Dust control motor X21
M6 Vacuum Motor X23
