Electrical System 141Service Manual – CS7000
Specications
Battery (Battery Model)
Capacity - 98 AH @ 20 HR
Low Voltage Cut Out
The low voltage cut out specication in use is set in the user options menu.
Menu # Cut Out AT: Restore Operation at: Battery Type
1 1.75v per cell (31.5v total) 2.15v per cell (38.7v total) Wet
2 1.83v per cell (32.9v total) 2.09v per cell (37.6v total) Gel
3 1.75v per cell (31.5v total) 2.09v per cell (37.6v total) (User Preference)
Battery Run Time (Battery powered machine)
Approx 5.4 hours (770 AH, 6 hr rate, and 900 AH 5 hr rate)
Auxiliary Relay
Winding Resistance: 652 Ohms
Auxiliary Contactor
Winding Resistance: 118 Ohms
