Engine System, Diesel 249Service Manual – CS7000

Special Tools

Diesel Compression Gauge

There are many brands of compression gauges

available.

Shown is a Snap-On EEPD500 Gauge kit

Compression Gauge Fitting for Glow Plug threads.

Shown is Snap-On TU-15-35

Threads - M8 X 1.0

Gauge Coupler

If using the Snap-On diesel compression EEPD500

Gauge kit and Snap-On TU-15-35 glow plug thread

tting, a coupler must be used to join the tting to the

gauge hose. Shown are Snap-On couplers M3569

and M3570
