Sweep System, Side Broom 401Service Manual – CS7000
Troubleshooting
Note: You can use the Service Mode to toggle the various system components on and off to check for
function. Refer to the Control System/Service Mode section for information on how to enter
and use the Service Mode.
Problem Cause Correction
The side sweep
system is not
operating correctly.
An interlock is not closed. Before you start troubleshooting a specic system,
check to make sure:
• The emergency stop switch (S15) on the Operator
control panel is disengaged (rotate clockwise).
• The safety relay from the steering system (K14) is
closed.
• The seat switch (S9) is closed.
• The battery interlock proximity sensor (S13) is
closed.
• The A1 Main Machine Controller is receiving the
appropriate signal from the A3 Control Panel via
the CAN BUS.
The side broom
motors will not run.
The 400-amp Fuse (
F1) is
blown.
Check the Fuse (F1) and replace if necessary.
Circuit breaker
CB7 is open. Reset circuit breaker CB7.
There is no voltage to the
K8
contactor coil.
1. Check circuit breakers CB1 and CB3 and reset if
necessary.
2. Check the K9 contactor coil resistance. If the coil
resistance is not 118 ohms ± 10%, replace the
contactor.
3. Check the continuity through contactor K9 with the
coil energized. If the contacts are open, replace
the contactor.
4. Check the J2-15 output from A1 Main Machine
Controller.
There is no positive voltage to
the side broom motors.
1. Check the wiring and connectors from the load
side of contactor K8 to the side broom motors and
repair as necessary.
2. Check the K8 contactor coil resistance. If the coil
resistance is not 118 ohms ± 10%, replace the
contactor.
3. Check the continuity through contactor K8 with the
coil energized. If the contacts are open, replace
the contactor.
There is no ground connection
to the side broom motors.
Check the wiring and connectors from the side broom
motors to battery ground repair as necessary.
