Nilfisk-Advance CS7000 - Engine Right Side View (Toward Front of Machine)

Engine System - Petrol (Gasoline) 211Service Manual – Haram Captor II
Engine Right Side View (Toward front of machine)
• Actuator
• Choke Solenoid
• Carburetor/mixer
• Engine RPM sensor
• Crank position sensor
• Petrol fuel shut off solenoid
• Fuel Select Connector
Actuator
Choke
Solenoid
Carburetor/mixer
Engine RPM sensor
LPG shut off solenoid
Crank position sensor
Petrol fuel shut off
solenoid
Fuel Select
Connector
