Hopper System 267Service Manual – CS7000
To Replace the Oil in the Hydraulic System
Note: Refer to the adjacent hydraulic system schematic
when disassembling and reassembling the
hydraulic power pack components.
1. Raise the hopper.
2. Engage the parking brake and remove the key from the key
switch.
3. Support the hopper in its raised position with
an overhead hoist or other suitable support.
Warning! The hopper must be
adequately and securely
supported with a hoist
or other suitable support
before the hopper lift
cylinder is disconnected.
The hopper prop rod cannot
be used to support the
hopper when the hopper lift
cylinder is disconnected or
removed.
