Hopper System 258Service Manual – CS7000
Troubleshooting
Note: You can use the Service Mode to toggle the various system components on and off to check for
function. Refer to the Control System/Service Mode section for information on how to enter
and use the Service Mode.
Problem Cause Correction
The hopper will not
rise or lower.
An interlock is not closed. Before you start troubleshooting the hopper system,
check to make sure:
The emergency stop switch (S15) on the Operator
control panel is disengaged (rotate clockwise).
The safety relay from the steering system (K14) is
closed.
The seat switch (S9) is closed.
The battery interlock proximity sensor (S13) is
closed (battery machines only).
The A1 Main Machine Controller is receiving the
appropriate signal from the A3 Control Panel via
the CAN BUS.
There is no voltage to the
K11 and K12 contactor coils.
Check circuit breaker CB1 and reset if necessary.
The contactor
K9 is not providing positive voltage to
the K11 and K12 contactor coils.
1. Check the K9 contactor coil resistance. If the coil
resistance is not 118 ohms ± 10%, replace the
contactor.
1. Check the continuity through contactor K9 with the
coil energized. If the contacts are open, replace
the contactor.
1. Check the J2-28 and J2-24 Outputs from A1 Main
Machine Controller.
There is no voltage to the
Hydraulic Pump/Motor
Assembly
M10.
Check circuit breaker CB8 and reset if necessary.
The contactors
K11 and K12 are not providing
voltage to the Hydraulic Pump/Motor Assembly M10.
1. Check the coil resistance on the K11 and K12
contactor. If the coil resistance is not 117 ohms ±
10%, replace the contactor.
1. Check the continuity through contactors K11 and
K12 with the coil energized. If the contacts are
open, replace the contactor.
2. Check the J2-28 and J2-24 Outputs from A1 Main
Machine Controller.
Check the motor wiring and connections from
contactors
K11 and K12 to the hydraulic pump motor,
and the ground connections from the contactors to
battery ground. Repair as necessary.
