Sweep System, Main 385Service Manual – CS7000
4. Remove the electrical connection cover. Remove the wires from the electrical connections. Note the
locations of the wires for reassembly.
5. Working from the gearbox end of the motor, remove the two long through bolts.
6. Pry off the end bell (cover) at the end opposite the gear box. Take care not to loose the rubber O-ring seal
or the wave washer.
7. Inspect the carbon brushes and replace as necessary. New brush length is approximately 7/8” (22 mm)
O-ring
Wave Washer
To Next Page
