Recovery System 297Service Manual – CS7000
4. Disconnect the Recovery Tank Vacuum Motor
Electrical Connector
.
Note: If your machine is equipped with
an extended scrub system, you
must disconnect the Float Switch
Wiring Harness
and Solution
Hose
before you can remove
the recovery tank. These are
described in steps 5 and 6. If
your machine is not equipped
with an extended scrub system,
skip to step 7.
5. Loosen the Knurled Collar and disconnect the
Float Switch Wiring Harness.
Recovery Tank
Vacuum Motor
Electrical Connector
Solution
Hose
Float Switch
Wiring
Harness
Knurled
Collar
Float Switch
Wiring
Harness
To Next Page
