Nilfisk-Advance CS7000 Service Manual

Wheel System, Traction 425Service Manual – CS7000
Troubleshooting Chart
Flash
Code
#
Programmer LCD
Display/ Effect Of Fault
Possible Cause(s) Set/Clear Conditions
47 Emer Rev HPD
ShutdownThrottle;
ShutdownEMBrake.
1. Emergency Reverse operation
has concluded, but the
throttle, forward and reverse
inputs, and interlock have not
been returned to neutral.
Set: At the conclusion of
Emergency Reverse, the fault
was set because various inputs
were not returned to neutral.
Clear: If EMR_Interlock = On,
clear the interlock, throttle,
and direction inputs. If
EMR_Interlock = Off, clear the
throttle and direction inputs.
49 Parameter Change Fault
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
FullBrake; ShutdownPump.
1. This is a safety fault caused
by a change in certain
parameter settings so that the
vehicle will not operate until
KSI is cycled. For example, if
a user changes the Throttle
Type this fault will appear
and require cycling KSI before
the vehicle can operate.
Set: Adjustment of a parameter
setting that requires cycling of
KSI.
Clear: Cycle KSI.
51 High Pedal Disable
ShutdownMotor;
1. There is an open in the
interlock circuit J4-9 (Seat
Switch, Emergency Switch,
Battery Interlock, Steering
Safety Relay).
Set: The drive pedal is outside
of the neutral position when
there is no voltage to the
interlock circuit J4-9
Clear: Voltage is supplied to
the interlock circuit pin J4-9
and the drive pedal is returned
to neutral.
68 VCL (Vehicle Control
Language) Run Time
Error
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
ShutdownInterlock;
ShutdownDriver1;
ShutdownDriver2;
ShutdownDriver3;
ShutdownDriver4;
ShutdownPD; FullBrake;
ShutdownPump.
1. VCL code encountered a
runtime VCL error.
2. See Monitor menu »
Controller: VCL Error Module
and VCL Error. This error
can then be compared to the
runtime VCL module ID and
error code denitions found
in the specic OS system
information le.
Set: Runtime VCL code error
condition.
Clear: Edit VCL application
software to x this error
condition; ash the new
compiled software and
matching parameter defaults;
cycle KSI.
