Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-116 P/N 196515 (Revision A)
Conveyor Controller
(P/N 62-1677-00 on
X1020, or P/N 62-1676 on
X1010) has failed.
Is LED D13
illuminated?
Exit FmNT, shut down
Windows NT and press the
black OFF (0) button on the
Operator’s Console
Switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from the facility outlet.
A
Connect the TS-03 Kit to the
SMEMA upstream and
downstream connectors.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
In the FmNT I/O SMEMA screen,
click Request board from
downstream tool.
Did LED 4 on the TS-
01 Box illuminate?
Exit FmNT, shut down Windows
NT, press black OFF (0) button
on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Remove the Side Cover from the
Conveyor Controller.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
In the FmNT I/O SMEMA screen,
click Request board from
downstream tool.
Locate the four SMEMA LEDs
near top of Conveyor Interface
PWA (just right of center).
Exit FmNT, shut down Windows
NT, press black OFF (0) button
on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Check continuity of SMEMA
Downstream Cable, routed
between Conveyor Controller and
the Rear Bulkhead of the
dispensing system. Pin
connections are specified in
Table 1.
8ShieldShell
3Purple9
9Yellow8
11Orange7
4Blue6
12Brown5
2Green4
10Red3
1White2
N/CBlack1
P2ColorP1
TABLE 1
Is there continuity?
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
Press Button 5 on the TS-01
Box.
SMEMA Downstream
Cable (P/N 06-4644-00)
has failed.
Yes
No
Yes
No
Yes
No
Conveyor Controller
(P/N 62-1677-00 on
X1020, or P/N 62-1676 on
X1010) has failed.
Is LED D13
illuminated?
Is LED D13
illuminated?
Exit FmNT, shut down
Windows NT and press the
black OFF (0) button on the
Operator’s Console
Switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from the facility outlet.
A
Connect the TS-03 Kit to the
SMEMA upstream and
downstream connectors.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
In the FmNT I/O SMEMA screen,
click Request board from
downstream tool.
Did LED 4 on the TS-
01 Box illuminate?
Did LED 4 on the TS-
01 Box illuminate?
Exit FmNT, shut down Windows
NT, press black OFF (0) button
on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Remove the Side Cover from the
Conveyor Controller.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
In the FmNT I/O SMEMA screen,
click Request board from
downstream tool.
Locate the four SMEMA LEDs
near top of Conveyor Interface
PWA (just right of center).
Exit FmNT, shut down Windows
NT, press black OFF (0) button
on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Check continuity of SMEMA
Downstream Cable, routed
between Conveyor Controller and
the Rear Bulkhead of the
dispensing system. Pin
connections are specified in
Table 1.
8ShieldShell
3Purple9
9Yellow8
11Orange7
4Blue6
12Brown5
2Green4
10Red3
1White2
N/CBlack1
P2ColorP1
TABLE 1
8ShieldShell
3Purple9
9Yellow8
11Orange7
4Blue6
12Brown5
2Green4
10Red3
1White2
N/CBlack1
P2ColorP1
TABLE 1
Is there continuity?Is there continuity?
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on the Operator’s
Console, and enter FmNT.
Press Button 5 on the TS-01
Box.
SMEMA Downstream
Cable (P/N 06-4644-00)
has failed.
Yes
No
Yes
No
Yes
No
Diagram Sheet 4-8-17
SMEMA Fault Isolation Procedure – Downstream Workpiece Transfer Verification
