Oce PlotWave 340 Operation Guide

Connect your Printing System
Working area [Footprint]
The printing system (with or without the optional [Océ Scanner Express]) requires a specific floor
space / working area as indicated in the illustration below.
1560mm
61.4”
1620mm
63.8”
1403mm
55.2”
60mm
2.4”
600mm
23.6”
803mm
31.6”
Connect your Printing System
22
Chapter 2 - Get to Know the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
