Oce PlotWave 340 Operation Guide

Remove a media roll
IMPORTANT
• Handle the media roll with care. A dented media roll can damage the printer.
• Do not open the media drawer during the printing process.
CAUTION
• Watch your fingers when you handle the media roll.
• When you want to remove an A0 media roll from position 2 make sure to bend your knees, as
indicated below, to spare your back.
Illustration
Procedure
1.
Pull firmly on the media drawer to open it.
Remove a media roll
258
Chapter 5 - Maintain the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
