Oce PlotWave 340 Operation Guide

Disconnect the network cable and the mains supply cable
Procedure
IMPORTANT
Make sure the main power switch (A) is in 'off' position.
1.
Disconnect the network cable from the network connection at the right back of the printer (C).
C
2.
Disconnect the mains supply cable from the wall socket.
3.
Disconnect the other side of the mains supply cable from the power connection at the left back of
the printer (B).
A
B
Disconnect the network cable and the mains supply cable
248
Chapter 5 - Maintain the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
