Oce PlotWave 340 Operation Guide

Clear a media jam in the roll feed section
Introduction
When a media jam in the roll feed section occurs, follow the help wizard on the user panel and
take the following steps:
Procedure
1.
Firmly pull the media drawer to open it.
2.
Remove any jammed printing material from the paper path and, if necessary, pull back the media
and rewind it.
3.
Reload the media roll if necessary, and press the [clean cut button] to trim a strip of the media
roll.
4.
Close the media drawer.
Clear a media jam in the roll feed section
316
Chapter 8 - Support

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
