Oce PlotWave 340 Operation Guide

Switch on the printing system
IMPORTANT
• Make sure the mains supply cable (A) is plugged in.
• Make sure the network cable (C) is plugged in.
Procedure
1.
Switch on the power switch at the left back of the printer (B).
A
B
C
2.
Press the on/off button at the front of the printer to start the system. The button lights up.
Switch on the printing system
24
Chapter 2 - Get to Know the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
