Oce PlotWave 340 Operation Guide

Connect the mains supply cable and the network cable
Procedure
IMPORTANT
Make sure the power switch (B) is in 'off' position.
1.
Plug the mains supply cable into the power connection at the left back of the printer (A).
A
B
C
2.
Plug the other side of the mains supply cable into the wall socket.
3.
Plug the network cable into the network connection at the right back of the printer (C), to connect
the printer to your company network.
Connect the mains supply cable and the network cable
Chapter 2 - Get to Know the Printing System
23

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
