Oce PlotWave 340 Operation Guide

1
2
4.
Align the roll with the centre of the correct size indicator on the roll holder and release the handle
of the locking mechanism.
NOTE
When you use a B1 media size (707 mm) you must align the media roll with the A1 indent.
5.
Remove the tapes from the new media roll.
Use both hands (as indicated) to place the media roll in the media drawer.
Load a media roll (position 2)
268
Chapter 5 - Maintain the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
