Oce PlotWave 340 Operation Guide

2
8.
If necessary, press the [clean cut button] to trim a strip of the new media roll. Press once for a
strip of approximately 20 cm, or hold the button and release it when the strip has the desired
length.
9.
Close the media drawer.
NOTE
Do not open the media drawer during loading.
10.
The user panel displays the message that new media is detected. Follow the steps in the wizard
to define the correct media type and size, when not detected automatically.
Load a media roll (position 2)
270
Chapter 5 - Maintain the Printing System

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
