Oce PlotWave 340 Operation Guide

Scan queue functionality
The scan jobs in line waiting to be sent to the right location are listed in the Scan queue. When a
job is succesfully sent, the job is removed from the queue.
Functionality Description
[Delete] To delete a job from the queue, select the job and click [Delete].
[Retry] To retry to send a job, select the job and click [Retry].
[Send to...] To send a job to a new destination, select the job and click [Send to...].
Then select the destination.
The Smart Inbox and the queue functionality
96
Chapter 3 - Define your Workflow with Océ Express WebTools

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
