Omron R88D-1SN ECT Series User Manual

Safety Precautions
24
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
• Do not store or install the Servo Drive in the following locations. Doing so may result in electric shock,
fire, equipment damage, or malfunction.
Locations subject to direct sunlight
Locations subject to temperatures outside the range specified in the specifications
Locations subject to humidity outside the range specified in the specifications
Locations subject to condensation as the result of severe changes in temperature
Locations subject to corrosive or flammable gases
Locations subject to dust (especially iron dust) or salts
Locations subject to exposure to water, oil, or chemicals
Locations subject to shock or vibration
• Medical electronics such as cardiac pacemakers may malfunction or injury may result.
• If an error occurs, remove the cause of the error and ensure safety, and then perform the error reset
and restart the operation. Injury, equipment damage, or burning may result.
• Do not move a power connector of a Servomotor with 4 kW or more over 5 times. Burning may result.
• Use a robot cable for the wiring to separately install the Servo Drive and Servomotor to moving and
fixed parts of the equipment. Equipment damage may result.
• Connect the Servo Drive to the Servomotor without a contactor, etc. Malfunction or equipment dam-
age may result.
Precautions for Safe Use
General Precaution
Mounting
Wiring

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
