Items to Check After Unpacking
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
*1. One short-circuit wire is connected.
*2. The connector with 3 terminals is included.
*3. The connector with 4 terminals is included.
*4. One opener is included.
*5. The connector with 2 terminals is included.
3-phase
400 VAC
600 W
Included
*1 *3
Included
*3
Included
*4
---
1 kW
1.5 kW
2 kW
3 kW
5.5 kW
Included
Included
*1
7.5 kW
15 kW
Included
*5
Specifications
Main circuit
connector B (CNB)
Motor connector
(CNC)
Control power
supply connector
(CND)
Main circuit
connector E
(CNE)

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
