Selection of Leakage Breaker for Servo Drive at 3 kW or less
Note These values vary greatly depending of the installation conditions of the motor power cable and the mea-
surement conditions. Use the values just as a reference.
Servo Drive
model
(R88D-)
Servomotor
model
(R88D-)
Input power
Leakage current
(3 m cable)
Increase per 10 m of
cable length
1SN01L-ECT 1M10030S Single-phase 100 V 0.6 mA 0.3 mA
1SN02L-ECT 1M20030S Single-phase 100 V
1SN04L-ECT 1M40030S Single-phase 100 V
1SN01H-ECT 1M10030T Single-phase 200 V 1.5 mA 1.3 mA
3-phase 200 V
1SN02H-ECT 1M20030T Single-phase 200 V
3-phase 200 V
1SN04H-ECT 1M40030T Single-phase 200 V
3-phase 200 V
1SN08H-ECT 1M75030T Single-phase 200 V
3-phase 200 V
1SN10H-ECT 1L1K030T 3-phase 200 V
1M1K020T 3-phase 200 V
1M90010T 3-phase 200 V
1SN15H-ECT 1L1K530T Single-phase 200 V 2.2 mA 1.9 mA
3-phase 200 V
1M1K520T Single-phase 200 V
3-phase 200 V
1SN20H-ECT 1L2K030T 3-phase 200 V
1M2K020T 3-phase 200 V
1M2K010T 3-phase 200 V
1SN30H-ECT 1L3K030T 3-phase 200 V
1M3K020T 3-phase 200 V
1M3K010T 3-phase 200 V
1SN06F-ECT 1M40020C 3-phase 400 V 1.9 mA 1.7 mA
1M60020C 3-phase 400 V
1SN10F-ECT 1L75030C 3-phase 400 V
1L1K030C 3-phase 400 V
1M1K020C 3-phase 400 V
1M90010C 3-phase 400 V
1SN15F-ECT 1L1K530C 3-phase 400 V
1M1K520C 3-phase 400 V
1SN20F-ECT 1L2K030C 3-phase 400 V 2.4 mA 3.0 mA
1M2K020C 3-phase 400 V
1M2K010C 3-phase 400 V
1SN30F-ECT 1L3K030C 3-phase 400 V
1M3K020C 3-phase 400 V
1M3K010C 3-phase 400 V
