1 Features and System Configuration
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
1-3 Names and Functions
1
1-3-1 Servo Drive Part Names
Motor connector
(CNC)
Encoder connector (CN2)
Brake interlock connector
(CN12)
terminal
