9 Details on Servo Parameters
9 - 68
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
• Selects the trigger to be used for the Latch Function 1.
• Mirror object of 60D0-01 hex
 Description of Set Values
• Gives the status of the Latch Function 1.
 Description of Set Values
• Gives the time which is latched by the Latch Function 1 (Touch Probe 1).
• Gives the position which is latched on the positive edge by the Latch Function 1 (Touch Probe 1).
• Mirror object of 60BA hex
Subindex 01 hex: Touch Probe 1 Source
Set
value
Description
1 External Latch Input 1 (EXT1)
2 External Latch Input 2 (EXT2)
6 Encoder Phase Z
Subindex 81 hex: Status
Set value Description
Bit 0 Enable or disable Latch Function 1
0 Disabled
1 Enabled
Bit 1 With or without Latch 1 positive data
0 Without latch data
1 With latch data
Subindex 83 hex: Positive Edge Time Stamp
Subindex 84 hex: Touch Probe 1 Positive Edge

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
