A-2 CoE Objects
A
A-2-8 Servo Drive Profile Object
• This object gives the supported modes of operation.
 Bit Descriptions
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default
setting
Data
attri-
bute
Size Access
PDO
map
Com-
plete
access
Modes of
operation
6502 --- Supported
drive modes
--- --- 000003A5
hex
--- 4 bytes
(U32)
RO --- Not pos-
sible
---
Bit Supported mode Value
0 pp (Profile position mode) 1: Supported
1 vl (Velocity mode) 0: Not sup-
ported
2 pv (Profile velocity mode) 1: Supported
3 tq (Profile torque mode) 0: Not sup-
ported
4 Reserved 0
5 hm (Homing mode) 1: Supported
6 ip (Interpolated position mode) 0: Not sup-
ported
7 csp (Cyclic synchronous position mode) 1: Supported
8 csv (Cyclic synchronous velocity mode) 1: Supported
9 cst (Cyclic synchronous torque mode) 1: Supported
10 to 31 Reserved 0

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
