Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
1077User Manual 1178.8520.02 ─ 01
HCOPy:CMAP<it>:HSL <hue>, <sat>, <lum>
This command selects the color for various screen elements in print jobs.
Suffix:
<it>
.
Selects the item for which the color scheme is to be defined.
Parameters:
<hue> hue
tint
Range: 0 to 1
<sat> sat
saturation
Range: 0 to 1
<lum> lum
brightness
Range: 0 to 1
Example:
HCOP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color
Manual operation: See "Defining User-specific Colors" on page 576
HCOPy:CMAP<it>:PDEFined <Color>
This command selects a predefined color for various screen elements in print jobs.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRay | LGRay | LBLue | LGReen | LCYan |
LRED | LMAGenta
Example:
HCOP:CMAP2:PDEF GRE
Manual operation: See " Predefined Colors " on page 575
HCOPy:DESTination<device> <Destination>
This command selects the destination of a print job.
Suffix:
<device>
.
Printing device.
Setting parameters:
<Destination> 'MMEM'
Sends the hardcopy to a file.
You can select the file name with MMEMory:NAME.
You can select the file format with HCOPy:DEVice:
LANGuage<device>.
Managing Settings and Results
