Measurements and Results
R&S
®
FSVA3000/ R&S
®
FSV3000
248User Manual 1178.8520.02 ─ 01
Table 7-14: Attributes and child nodes of the PowerClass element
Child Node Attribute Value Parameter description Mand.
StartPower Value <power in dBm> The start power must be equal
to the stop power of the previ-
ous power class. The Start-
Power value of the first range
is -200
Yes
Unit dBm Yes
InclusiveFlag true Yes
StopPower Value <power in dBm> The stop power must be equal
to the start power of the next
power class. The StopPower
value of the last range is 200
Yes
Unit dBm
InclusiveFlag false Yes
DefaultLimitFailMode Absolute | Relative
| Absolute and Rel-
ative | Absolute or
Relative
Yes
Table 7-15: Attributes and child nodes of the Range element (normal ranges)
Child node Attribute Value Parameter description Mand.
Index 0…19 Indices are continuous and
have to start with 0
Yes
Name <string> Name of the range Only if Referen-
ceChannel con-
tains a name and
the range is the
reference range
Short-
Name
<string> Short name of the range No
ChannelType TX | Adjacent Yes
WeightingFilter Only if Referen-
cePower method
is TX Channel
Power and the
range is the ref-
erence range
Type RRC | CFilter Type of the weighting filter Yes
Roll Off Factor 0…1 Excess bandwidth of the fil-
ter
Only if the filter
type is RRC
Bandwidth <bandwidth in Hz> Filter bandwidth Only if the filter
type is RRC
FrequencyRange Yes
Start <frequency in Hz> Start value of the range Yes
Stop <frequency in Hz> Stop value of the range Yes
Spectrum Emission Mask (SEM) Measurement
