7.6.8.2 ASCII File Export Format (Spectrum Emission Mask)
When trace data from an SEM measurement is exported, the data is stored in ASCII
format as described below. The first part of the file lists information about the signal
analyzer and the general setup.
File contents Explanation
File header
Type;FSVA3-26; Model
Version;1.00; Firmware version
Date;31.Mar 17; Storage date of data set
Mode;ANALYZER;SEM; Operating mode and measurement function
Center Freq;13250000000.000000;Hz X-axis settings
Freq Offset;0.000000;Hz
Span;25500000.000000;Hz
x-Axis;LIN;
Start;13237250000.000000;Hz
Stop;13262750000.000000;Hz
Level Offset;0.000000;dB Y-axis settings
Ref Position;100.000000;%
y-Axis;LOG;
Level Range;100.000000;dB
Trace settings
Trace Mode;CLR/WRITE;
Detector;RMS;
Sweep Count;0;
Trace 1:;
x-Unit;Hz;
y-Unit;dBm;
List evaluation settings
Margin;200; Peak List margin
Reference range settings
RefType; CPOWER; Reference power type
TxBandwidth;3840000;;Hz Channel power settings
Filter State; ON;
Alpha;0.22;
Spectrum Emission Mask (SEM) Measurement
