Remote command:
CALCulate<n>:STATistics:SCALe:X:RANGe on page 843
Shifting the Display ( Offset ) ← X-Axis
Defines an arithmetic level offset. This offset is added to the measured level irrespec-
tive of the selected unit. The scaling of the x-axis is changed accordingly. The setting
range is ±200 dB in 0.1 dB steps.
Remote command:
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet on page 900
Y-Axis
Defines the scaling settings for the probability distribution.
Y-Unit ← Y-Axis
Defines the scaling type of the y-axis as either percentage or absolute. The default
value is absolute scaling.
Remote command:
CALCulate<n>:STATistics:SCALe:Y:UNIT on page 844
Y-Max / Y-Min ← Y-Axis
Defines the upper (max) and lower (min) limit of the displayed probability range. Values
on the y-axis are normalized which means that the maximum value is 1.0. The mini-
mum value must be in the range:
1E-9 < Y-Min < 0.1
The distance between "Y-Max" and "Y-Min" must be at least one decade.
Remote command:
CALCulate<n>:STATistics:SCALe:Y:UPPer on page 844
CALCulate<n>:STATistics:SCALe:Y:LOWer on page 844
Default Settings
Resets the x- and y-axis scalings to their preset values.
X-axis ref level: -10 dBm
X-axis range APD: 100 dB
X-axis range CCDF: 20 dB
Y-axis upper limit: 1.0
Y-axis lower limit: 1E-6
Remote command:
CALCulate<n>:STATistics:PRESet on page 842
Adjust Settings
Adjusts the level settings according to the measured difference between peak and min-
imum power for APD measurement or peak and mean power for CCDF measurement
in order to obtain maximum power resolution. Adjusts the reference level to the current
input signal.
