Value ← Marker Y Pos ← Choose Event
Value with which the marker value is compared.
Result Value ← Choose Event
The value of a specific result triggers the actions. Depending on the currently selected
measurement, different result values are available (see Chapter 7, "Measurements and
Results", on page 120, Chapter 12.3.4, "Reference: Overview of Available Result-
Events", on page 589).
Application ← Result Value ← Choose Event
Selects the (active) application whose current measurement results are displayed for
configuration. Since the available measurement results depend on the channel's mea-
surement function, you must specify which channel to look for results in.
For example, to define a rule based on the spectrum emission mask Tx power, the
SEM measurement must be active in the selected application before configuring the
rule.
Result ← Result Value ← Choose Event
The measurement result whose value is evaluated (see also Chapter 12.3.4, "Refer-
ence: Overview of Available Result-Events", on page 589).
Trigger condition (Value is) ← Result Value ← Choose Event
The relation of the result value to the specified value ("greater than" / "lower than") that
triggers the actions
Value ← Result Value ← Choose Event
Value with which the result value is compared.
Limit Check ← Choose Event
The limit check for a specific result triggers the actions. Depending on the currently
selected measurement, different results are available (see Chapter 7, "Measurements
and Results", on page 120, Chapter 12.3.4, "Reference: Overview of Available Result-
Events", on page 589).
Application ← Limit Check ← Choose Event
Selects the (active) application whose current measurement results are displayed for
configuration. Since the available measurement results depend on the channel's mea-
surement function, you must specify which channel to look for results in.
Event-based Actions
