[SENSe:]BWIDth:VIDeo:RATio <Ratio>
[SENSe:]BANDwidth:VIDeo:RATio <Ratio>
This command defines the coupling ratio of the video bandwidth to the resolution band-
width (RBW/VBW).
Parameters:
<Ratio> Range: 0,001 to 1000
*RST: 1
Example:
BAND:VID:RAT 3
Sets the coupling of video bandwidth to video bandwidth =
3*resolution bandwidth
Manual operation: See " RBW/VBW " on page 385
[SENSe:]BWIDth:VIDeo:TYPE <Mode>
[SENSe:]BANDwidth:VIDeo:TYPE <Mode>
This command selects the position of the video filter in the signal path.
Parameters:
<Mode> LINear
The video filter is applied in front of the logarithmic amplifier.
In linear mode, measurements with a logarithmic level scale
result in flatter falling edges compared to logarithmic mode. The
reason is the conversion of linear power values into logarithmic
level values: if you halve the linear power, the logarithmic level
decreases by 3 dB.
LOGarithmic
The video filter is applied after the logarithmic amplifier
*RST: LOGarithmic
Example:
BAND:VID:TYPE LIN
Video filter ahead of the logarithmic amplifier
14.7.2.2 Configuring the Sweep
Useful commands for configuring sweeps described elsewhere:
●
[SENSe:]AVERage<n>:COUNt on page 963
●
[SENSe:]AVERage<n>[:STATe<t>] on page 963
●
[SENSe:]AVERage<n>:TYPE on page 963
Remote commands exclusive to configuring sweeps:
[SENSe:]SWEep:COUNt.................................................................................................895
[SENSe:]SWEep:DURation?........................................................................................... 895
[SENSe:]SWEep:OPTimize.............................................................................................896
[SENSe:]SWEep[:WINDow<n>]:POINts............................................................................896
[SENSe:]SWEep:TIME................................................................................................... 897
[SENSe:]SWEep:TIME:AUTO......................................................................................... 897
