(TRACE1-TRACE3)
Subtracts trace 3 from trace 1.
(TRACE1-TRACE4)
Subtracts trace 4 from trace 1.
(TRACE1-TRACE5)
Subtracts trace 5 from trace 1.
(TRACE1-TRACE6)
Subtracts trace 6 from trace 1.
Example:
CALC:MATH:STAT ON
Turns trace mathematics on.
CALC:MATH:EXPR:DEF (TRACE1-TRACE3)
Subtracts trace 3 from trace 1.
Manual operation: See " Trace Math Function " on page 517
CALCulate<n>:MATH<t>:MODE <Mode>
This command selects the way the R&S FSV/A calculates trace mathematics.
Suffix:
<n>
.
Window
<t> irrelevant
Parameters:
<Mode> For more information on the way each mode works see Trace
Math Mode.
LINear
Linear calculation.
LOGarithmic
Logarithmic calculation.
POWer
Linear power calculation.
*RST: LOGarithmic
Example:
CALC:MATH:MODE LIN
Selects linear calculation.
Manual operation: See " Trace Math Mode " on page 517
CALCulate<n>:MATH<t>:POSition <Position>
This command defines the position of the trace resulting from the mathematical opera-
tion.
Suffix:
<n>
.
Window
<t> irrelevant
