R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
292Operating Manual 1407.0806.32 ─ 21
Return values:
<DialogIdList> string
Example:
DISP:DIAL:ID?
Response: "<dialog ID(1)> <dialog ID(2)> ...
<dialog ID(n)>"
Returns the dialog identifiers of all opened dialogs.
Usage: Query only
:DISPlay:DIALog:OPEN
<DialogId>
Opens the specified dialog. To determine the dialog identifier, use command :
DISPlay:DIALog:ID?.
Setting parameters:
<DialogId> string
Example:
DISP:DIAL:OPEN "<dialog ID>"
Opens the dialog, determined with the "<dialog ID>".
Usage: Setting only
:DISPlay:PSAVe:HOLDoff <HoldoffTimeMin>
Sets the waiting time for the screen-save mode of the display.
Parameters:
<HoldoffTimeMin> integer
Range: 1 to 60
*RST: 10
Default unit: minute
Example:
DISP:PSAV:HOLD 8
Sets the timeout of the screen saver to 8 minutes.
Manual operation: See "Wait Time" on page 108
:DISPlay:PSAVe[:STATe] <State>
Activates the screen-save mode of the display.
If activated, the display including backlight is switched off after the wait time elapses
and if no entries via front panel, external mouse or external keyboard are made. To set
the wait time, use command :DISPlay:PSAVe:HOLDoff.
This mode is recommended for protecting the display, especially if you operate the
instrument via remote control.
Parameters:
<State> 0 | 1 | OFF | ON
*RST: 0
DISPlay Subsystem
