R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
333Operating Manual 1407.0806.32 ─ 21
The ASCII files are stored with the fixed file extensions *.txt or *.csv in a directory
of the user's choice. The directory applicable to the commands is defined with the com-
mand MMEMory:CDIR. A path can also be specified in command
SOUR:CORR:DEXC:AFIL:SEL, in which case the files are stored or loaded in the
specified directory.
Parameters:
<Filename> <ascii file name>
Example:
CORR:DEXC:MODE IMP
selects that ASCII files with frequency and level value pairs are
imported and transferred into user correction lists.
CORR:DEXC:AFIL:SEL '/var/user/import_ucor.csv'
selects that ASCII file ucor.csv is imported.
CORR:DEXC:SEL '/var/user/import_ucor_imp'
selects that the ASCII file ucor.csv is imported into user cor-
rection list ucor_imp.
Manual operation: See "Select ASCII Source / Destination - User Correction"
on page 162
[:SOURce<hw>]:CORRection:DEXChange:AFILe:SEParator:COLumn <Column>
Selects the separator between the frequency and level column of the ASCII table.
Parameters:
<Column> TABulator | SEMicolon | COMMa | SPACe
*RST: COMMa
Example:
CORR:DEXC:MODE EXP
selects that the user correction list is exported into an ASCII file.
CORR:DEXC:AFIL:SEL '/var/user/import_ucor.csv'
selects ASCII file ucor.csv as destination for the user correction
list data.
CORR:DEXC:AFIL:SEP:COL TAB
the pairs of frequency and level values are separated by a tabu-
lator.
CORR:DEXC:AFIL:SEP:DEC DOT
selects the decimal separator dot.
CORR:DEXC:SEL '/var/user/import_ucor_imp'
selects that the user correction list ucor_imp is imported into
ASCII file ucor.csv.
Manual operation:
See "Column Separator- User Correction" on page 162
[:SOURce<hw>]:CORRection:DEXChange:AFILe:SEParator:DECimal <Decimal>
Selects the decimal separator used in the ASCII data between '.' (decimal point) and ','
(comma) with floating-point numerals.
SOURce Subsystem
