R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
334Operating Manual 1407.0806.32 ─ 21
Parameters:
<Decimal> DOT | COMMa
*RST: DOT
Example:
CORR:DEXC:MODE EXP
selects that the user correction list is exported into an ASCII file.
CORR:DEXC:AFIL:SEL '/var/user/import_ucor.csv'
selects ASCII file ucor.csv as destination for the user correction
list data.
CORR:DEXC:AFIL:SEP:COL TAB
the pairs of frequency and level values are separated by a tabu-
lator.
CORR:DEXC:AFIL:SEP:DEC DOT
selects the decimal separator dot.
CORR:DEXC:SEL '/var/user/import_ucor_imp'
selects that the user correction list ucor_imp is imported into
ASCII file ucor.csv.
Manual operation:
See "Decimal Point - User Correction" on page 162
[:SOURce<hw>]:CORRection:DEXChange:EXECute
Starts the export or import of the selected file. When import is selected, the ASCII file is
imported as user correction list. When export is selected, the user correction list is
exported into the selected ASCII file.
Example:
CORR:DEXC:MODE IMP
selects that ASCII files with frequency and level value pairs are
imported and transferred into user correction lists.
CORR:DEXC:AFIL:SEL '/var/user/import_ucor.csv'
selects that ASCII file ucor.csv is imported.
CORR:DEXC:SEL '/var/user/import_ucor_imp'
selects that the ASCII file ucor.csv is imported into user cor-
rection list ucor_imp.
CORR:DEXC:EXEC
starts the import of the ASCII file data into the user correction
file.
Usage:
Event
Manual operation: See "Import / Export - User Correction" on page 162
[:SOURce<hw>]:CORRection:DEXChange:MODE <Mode>
Selects if user correction lists should be imported or exported. Depending on the selec-
tion her, the file select command define either the source or the destination for user
correction lists and ASCII files.
Parameters:
<Mode> IMPort | EXPort
*RST: IMPort
SOURce Subsystem
